Gigabyte B560M DS3H AC Intel 10th and 11th Gen Micro ATX Motherboard
Quick Overview
- Gigabyte B560M DS3H AC
- CPU Sockets - LGA1200
- Chipset - Intel B560 Express
- Generation - 10th/11th Gen
- Memory Channel - Dual
Availability:
In stock
Email to a Friend:
Description
Specification | |
Brand | Gigabyte |
Model | B560M DS3H AC |
Supported CPU | 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors |
10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors | |
Chipset | Intel B560 Express Chipset |
BIOS | 1 x 256 Mbit flash |
Use of licensed AMI UEFI BIOS | |
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
Audio | Realtek Audio CODEC |
High Definition Audio | |
2/4/5.1/7.1-channel | |
Expansion Slots | |
PCI | 1 x PCI Express x16 slot, running at x16 |
(The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note) | |
2 x PCI Express x1 slots | |
(The PCIEX1 slot conforms to PCI Express 3.0 standard.) | |
M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note) |
Chipset: | |
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB) | |
Memory | |
Type | Dual-channel memory architecture |
Slots | 4 x DDR4 DIMM |
Supported Memory | 11th Generation Intel Core i9/i7/i5 processors: |
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz | |
10th Generation Intel Core i9/i7 processors: | |
Support for DDR4 2933/2666/2400/2133 MHz memory modules | |
10th Generation Intel Core i5/i3/Pentium/Celeron processors: | |
Support for DDR4 2666/2400/2133 MHz memory modules | |
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory | |
Dual-channel memory architecture | |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Support for Extreme Memory Profile (XMP) memory modules | |
Maximum Memory | 128 GB (32 GB single DIMM capacity) |
Graphics | |
Graphics | Integrated Graphics Processor-Intel HD Graphics support: |
1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz | |
* Support for DisplayPort 1.2 version and HDCP 2.3 | |
* When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only. | |
1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz | |
* Support for HDMI 1.4 version and HDCP 2.3. | |
Connector & Ports | |
HDMI | 1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz |
Display Port (s) | 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
D-Sub (s) | Yes |
USB (s) | Chipset: |
1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support | |
5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) | |
4 x USB 2.0/1.1 ports available through the internal USB headers | |
Chipset+USB 2.0 Hub: | |
2 x USB 2.0/1.1 ports on the back panel | |
LAN Port (s) | Realtek GbE LAN chip (1000/100 Mbit) |
Supported Storage | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note) |
Chipset: | |
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB) | |
6 x SATA 6Gb/s connectors | |
Intel Optane Memory Ready | |
Audio | 3 x audio jacks |
Internal I/O Ports | 1 x 24-pin ATX main power connector |
1 x 8-pin ATX 12V power connector | |
1 x CPU fan header | |
3 x system fan headers | |
1 x addressable LED strip header | |
1 x RGB LED strip header | |
6 x SATA 6Gb/s connectors | |
2 x M.2 Socket 3 connectors | |
1 x front panel header | |
1 x front panel audio header | |
1 x USB 3.2 Gen 1 header | |
2 x USB 2.0/1.1 headers | |
1 x Clear CMOS jumper | |
1 x Q-Flash Plus button | |
TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
Others | |
Special Features | Support for APP Center |
@BIOS | |
EasyTune | |
Fast Boot | |
Game Boost | |
ON/OFF Charge | |
RGB Fusion | |
Smart Backup | |
System Information Viewer | |
Support for Q-Flash Plus | |
Support for Q-Flash | |
Support for Xpress Install | |
Bundled Software | Norton Internet Security (OEM version) |
Realtek 8118 Gaming LAN Bandwidth Control Utility | |
Warranty Information | |
Manufacturing Warranty | 3 Years Warranty |
